DFIR ELK Setup Guide

The following is a step-by-step guide on setting up a DFIR ELK instance on Windows.

Step 1: Prerequisites

Before installation, ensure:

• Windows 10/11 or Windows Server 2016+ (64-bit)

• Java JDK 17 (Required for Elasticsearch & Logstash)

• At least 8GB RAM (16GB+ recommended)

• Administrator privileges

• PowerShell 5.1+

Step 2: Install Java JDK 17

ELK requires Java. Download and install:

1. Download JDK 17 from Oracle or Adoptium.

2. Run the installer and follow prompts.

3. Set JAVA_HOME environment variable:

   • Open System Properties > Environment Variables.

   • Add a new variable:





     Copy



     Download

     Variable: JAVA_HOME
     Value: C:\Program Files\Java\jdk-17.x.x (your JDK path)

   • Update Path variable to include %JAVA_HOME%\bin.

Step 3: Download & Configure Elasticsearch

1. Download Elasticsearch (v8.x) from Elastic.co.

2. Extract the ZIP to C:\ELK\elasticsearch.

3. Configure Elasticsearch:

   • Open C:\ELK\elasticsearch\config\elasticsearch.yml in a text editor.

   • Modify:

     yaml



     Copy



     Download

     cluster.name: dfir-cluster
     node.name: dfir-node
     network.host: 0.0.0.0
     http.port: 9200
     discovery.type: single-node  # For single-node setup
     xpack.security.enabled: false  # Disable security for testing (enable in prod)

4. Run Elasticsearch:

   • Open PowerShell as Admin and execute:

     powershell



     Copy



     Download

     cd C:\ELK\elasticsearch\bin
     .\elasticsearch.bat

   • Verify it’s running:
     Open http://localhost:9200 in a browser (should return JSON).

Step 4: Install & Configure Logstash

1. Download Logstash from Elastic.co.

2. Extract to C:\ELK\logstash.

3. Create a DFIR Pipeline Config:

   • Open C:\ELK\logstash\config\logstash-sample.conf and modify:

     conf



     Copy



     Download

     input {
       file {
         path => "C:\DFIR_Logs\*.log"  # Path to forensic logs (e.g., Sysmon, Windows Event Logs)
         start_position => "beginning"
       }
     }
     filter {
       grok {  # Parse logs (customize for your log format)
         match => { "message" => "%{TIMESTAMP_ISO8601:timestamp} %{LOGLEVEL:loglevel} %{GREEDYDATA:message}" }
       }
     }
     output {
       elasticsearch {
         hosts => ["http://localhost:9200"]
         index => "dfir-logs-%{+YYYY.MM.dd}"
       }
     }

4. Run Logstash:

   powershell



   Copy



   Download

   cd C:\ELK\logstash\bin
   .\logstash.bat -f C:\ELK\logstash\config\logstash-sample.conf

Step 5: Install & Configure Kibana

1. Download Kibana from Elastic.co.

2. Extract to C:\ELK\kibana.

3. Configure Kibana:

   • Open C:\ELK\kibana\config\kibana.yml and modify:

     yaml



     Copy



     Download

     server.port: 5601
     server.host: "0.0.0.0"
     elasticsearch.hosts: ["http://localhost:9200"]

4. Run Kibana:

   powershell



   Copy



   Download

   cd C:\ELK\kibana\bin
   .\kibana.bat

5. Access Kibana:

   • Open http://localhost:5601 in a browser.

   • Go to Discover > Create Index Pattern (dfir-logs-*).

Step 6: Ingest DFIR Data (Example: Sysmon Logs)

1. Install Sysmon (if not already):

   powershell



   Copy



   Download

   sysmon.exe -i -accepteula -h md5,sha256 -l -n

2. Forward Sysmon logs to Logstash:

   • Use Winlogbeat or NXLog to send Windows Event Logs to Logstash.

   • Example Winlogbeat config (winlogbeat.yml):

     yaml



     Copy



     Download

     winlogbeat.event_logs:
       - name: Microsoft-Windows-Sysmon/Operational
     output.logstash:
       hosts: ["localhost:5044"]

Step 7: Visualize DFIR Data in Kibana

1. Create Dashboards:

   • Go to Kibana > Dashboard.

   • Import pre-built DFIR dashboards (e.g., Sigma Detection Dashboards).

2. Example Visualizations:

   • Timeline of Suspicious Processes

   • Network Connections Heatmap

   • Malware Detection Alerts
